Innovative features
Pufferfish℠ Silicone Soft Cap
The proprietary ESSEX Pufferfish℠ Silicone soft cap allows tactile control of 5 major controls on the upper deck of the Q2 without annoying protrusions and penetrations common to mechanical controls. We use a industry proven Shore A 30 durometer platinum curing silicone rubber designed for mold making, encapsulation applications, pressure pads, gaskets, and various other types of parts. Designed to last, to stay flexible and to be water clear.
Easily access the Q2s
Main Switch
Shutter Button
Thumbwheel
Thumbwheel button
Shutter Speed Setting Dial
Jellyfish℠ vinyl LCD Window
ESSEX’s revolutionary Jellyfish℠ vinyl rear window allows you to see and manipulate 5 major controls on the LCD back panel of the Q2 camera. Under certain circumstances the Jellyfish℠ vinyl window also allows finger control of the touch screen. The Jellyfish℠ vinyl window material is 20-gauge press-polished with good optical clarity and durability. It is a standard marine grade window material manufactured from 100% polyvinyl chloride with a highly polished finish that results in a soft, flexible, press-polished sheet. This clear vinyl window material is perfect for marine windows and is used extensively in the maritime industry and was a logical choice for use on the Amphibie.
Easily view the LCD panel and access:
PLAY Button
FUNCTION Button
MENU Button
Directional Pad
Center Button
The vinyl window is a flexible membrane and as such it does have some interesting characteristics.
It is extremely puncture resistant and durable and the 20 gauge thickness (.0375” / .95mm) was chosen for its thickness versus flexibility
Art Brewer (Essex Proteam Captain) has seen it all when it comes to waterhousing design and construction during his fifty plus years of water photography and Art approves of the innovative use of vinyl in this application.
Mr. Brewer reports that under certain environmental conditions, the vinyl window will slightly puff outward or inward and this is normal behavior. Increased pressure due to depth will cause it to slightly puff inward and depth tests without the camera installed see the window puff inwards quite dramatically. The 3M VHB™ (Very High Bond) tape used to install the vinyl window holds the vinyl window securely, akin to a tensioned drum head hoop. Conversely, at times the vinyl window may puff slightly outwards and this is due to the interior of the Amphibie warming up, as hot air expands. The buildup of heat inside the Amphibie is negligible and does not present issues as is found with using a RED, SONY or other type of high heat generating sensor camera inside of a waterhousing.
Seal Screw
Most waterhousings use buffers, shims and or pads to secure the camera in the housing so it won’t move around. We prefer to use an old school waterhousing technique that involves anchoring the camera via the camera’s tripod thread. Anchoring the camera to the housing like you would anchor your camera to a tripod insures that the Q2 stays put while in the housing. Anchoring is accomplished utilizing a “seal screw”, a smart, aesthetic design that incorporates a rubber O-ring under the screw head, thus granting both insurmountable sealing and fastening power to the fastener. A malleable O-ring fits with tight precision under the screw forming a sealant layer between the fastener and the harsh ocean environment. The seal screw fastener is designed for bi-directional sealing, thus offering protection in all directions (axially, radially, angularly). It is also very easy to use, as it don’t necessitate any special preparation or re-tightening.
The Amphibie’s Seal Screw has a permanent storage location inside the housing so it won’t get lost and in case it does, simply look under the foam on the lid of the Amphbie hard case to find a supplemental seal screw waiting to be used in case of emergency. Also under the lid foam is a wingut that can be used with the seal screw when you want to water test the housing without the camera.
Replacable Front Lens Element
The Lens Ring Assembly used on the Q2 Amphibie is taken from the Essex Bayonet Port Mount system used on our custom waterhousings.
Unscrew the Retaining Ring and the Plexiglas front lens element and the O-Ring are easily replaced in the field.
The standard Plexiglas front element can be swapped out for a 4.5” Tiffen clear filter if the photographer desires to shoot through glass.
Plexiglas Hatch
The Q2 Amphibie Plexiglas Hatch is elegant and simple in its design.
Laser cut from 3/8” (9.5mm) Cast Acrylic
A slight radius is applied to the outer edges to keep things smooth
The edge and the radii are then hand buffed and polished for a fine finish
Captive retaining screws insure that the hatch is ready to be battened down at a moments notice using the supplied screw tool
All hardware is 318 Stainless Steel to keep corrossion at bay
Pro tested
ART BREWER
For over fifty years I’ve made and used waterhousings starting out with a George Greenough housing he’d built for Surfer Magazine, and I was fortunate enough to use it for a few years. Since then I’ve owned dozens of waterhousings. Over the last 15 years I’ve been lucky enough to know and build a friendship with Mike and at the same time collaborate with him on ideas and design on various housings he’s built; he’s the go-to guy with new techniques and innovations. When I purchased my new Leica Q2 camera over a year and a half ago, all I could think about was making a housing for this amazing camera so I called Mike and we got together and talked about it. Mike then made a series of 3 or 4 prototypes, tested, made adjustments, and tested again—and again—until he came up with this final version of the Amphibie, making it the perfect match for the Leica legend and my Q2 to get in the water… and the rest is history.
— Art Brewer
The Kit
Q2 Amphibie KIT FOR LEICA Q2 digital camera
The Q2 Amphibie waterhousing kit comes with all the items you’ll need to protect your Leica from H2O situations.
